Rob Cosman's Wood-Hinge Drill Kit (Imperial)

41 reviews

Regular price $139.95 USD Sale

145 left in stock.
Gallery
Full Description
Customer Reviews
KITs

Master craftsman Dale Nish taught me how to make an amazing wood-hinge for boxes.  A wooden dowel is cut into segments, a shallow hole is drilled in the center of each dowel and a small pin is inserted into the hole for the dowel segments to pivot on.

I've made thousands of boxes using this style of hinge and I have designed four drill jigs to precisely drill the hole in the center of dowel segments (the most difficult task).  These jigs are available as a complete kit or as individual drill jigs.

Wood-Hinge Drill Kit (Imperial) Without Rods:

  • My imperial sized kit allows you to drill 1/16 inch and 1/8 inch size holes in 1/4 inch,  1/2 inch, 3/8 inch, and 3/4 inch diameter dowels.
  • Kit includes 1/16 inch and 1/8 inch drill bit holders; 1/4 inch, 3/8 inch, 1/2 inch, and 3/4 inch drill jigs; 1/16 inch and 1/8 inch drill bits; and a 1/16 inch Allen wrench.

  • 1/16 inch drill bit is used with 1/4 inch and 3/8 inch diameter dowels.

  • 1/8 inch drill bit is used for the 1/2 inch and 3/4 inch diameter dowels.

  • Opposing set screws hold the drill bit securely and allow for adjustment of the hole depth.

  • Rod kits are available for separate purchase.

  • You may also like to purchase a copy of my video "Wood-Hinge Box" which shows you step-by-step how to build a wood-hinge box and use my drill jigs to create a wood-hinge.





Customer Reviews

Based on 32 reviews Write a review
Customer Reviews
5.0 Based on 41 Reviews
5 ★
95%
39
4 ★
5%
2
3 ★
0%
0
2 ★
0%
0
1 ★
0%
0
Customer Photos
Write a Review Ask a Question

Thank you for submitting a review!

Your input is very much appreciated. Share it with your friends so they can enjoy it too!

Filter Reviews:
CL
02/07/2023
Charles L.
United States United States

Absolutely Worth the $$$

Excellent jig. Don't waste your time and money (as I did) trying to make your own. Works great! Very well made! I would suggest the addition of a small quantity of 1/16" rods just to get started.

TC
01/21/2023
Tracey C.
United States United States

Wood hinge kit

Excellent, simple product but machined well, cost was reasonable and worked great.

RobCosman.com Rob Cosman's Wood-Hinge Drill Kit (Imperial) Review
MG
01/17/2023
Marc G.
United States United States

Expensive

Very nice product. The price reflects the quality. The machining is very good. I bought the whole set as opposed to individually purchasing each one to save money. It is a very simple setup and saves a lot of time. Rob called me personally after purchasing it to thank me which is top notch.

JC
01/17/2023
Jessica C.
United States United States

The best

incredible I saved your voicemail and will listen to it b4 each woodworking session just to get inspired...don't tell my wife lol! jk great quality product

A RobCosman.com Customer
DL
01/01/2023
Dwight L.
United States United States

Jig for wooden dowel hinges

Very easy to use the jig with premade dowels. Had a devil of time making my own dowels of cherry for the cherry tea boxes (4) that I was making. Getting the hang of making your own dowels takes a good bit of practice.
